2 SIDED NESTABLE ROLL CAGE WITH ANTIFALL FLAPS
This Rollcontainer is a must-have in the supply chain to optimise logistic flows while securing products thanks to its fall prevention components.
Application areas : large and medium distribution, supermarkets, grocery shops, etc
All special requests for a product in the category are analyzed by our Design Department.
Material / Coating: Electrogalvanised CR3
Service load: 500 Kg
Average weight: 42 Kg
Sides:
Panel mesh : 135 x 145 mm
½ shelves:
Nb. of ½ shelves : 2
Service load : 75 kg by ½ shelf
Specificity : plastic protection on hooks and articulations
Base:
Height base / floor : 190 mm
Base mesh : 65 x 90 mm
Specificity : plastic protection on hooks and articulations
Wheels:
2 fixed wheels – 2 swivel wheels
Wheels material : sandwich PA or PP
Wheels diameter : Fixed at rear 125 mm – swivel at front diam. 100 mm
Plates / Label Holders:
Bar code support : 12 x 180 mm
Label-holders : 140 x 150 mm
Data sheet
- Ext width
- 755 mm
- Ext depth
- 826 mm
- Ext height
- 1890 mm
- Int width
- 662 mm
- Int depth
- 800 mm
- Int height
- 1700 mm
Material / Coating: Electrogalvanised CR3
Service load: 500 Kg
Average weight: 42 Kg
Sides:
Panel mesh : 135 x 145 mm
½ shelves:
Nb. of ½ shelves : 2
Service load : 75 kg by ½ shelf
Specificity : plastic protection on hooks and articulations
Base:
Height base / floor : 190 mm
Base mesh : 65 x 90 mm
Specificity : plastic protection on hooks and articulations
Wheels:
2 fixed wheels – 2 swivel wheels
Wheels material : sandwich PA or PP
Wheels diameter : Fixed at rear 125 mm – swivel at front diam. 100 mm
Plates / Label Holders:
Bar code support : 12 x 180 mm
Label-holders : 140 x 150 mm
